5-126 C30 Controller System GE Multilin
5.6 CONTROL ELEMENTS 5 SETTINGS
5
5.6.6 8-BIT SWITCHES
PATH: SETTINGS  CONTROL ELEMENTS  8-BIT SWITCHES  8-BIT SWITCH 1(6)
This feature allows switching between two input arguments defined by 8 bits each. The bits are specified by FlexLogic oper-
ands. The feature could be viewed as an integrated two-position switch for 8 logic signals.
Typically this element is applied in conjunction with the Digitizer and 8-bit Comparator features.
The switch runs every half power cycle (every four protection passes).
• 8BIT SW 1 ARG A0 to 8BIT SW 1 ARG A7: These settings specify FlexLogic operands that constitute the first (A)
input of the switch. These operands are routed to the output operands if the control input is in the "Off" position.
• BIT SW 1 ARG B0 to 8BIT SW 1 ARG B7: These settings specify FlexLogic operands that constitute the second (B)
input of the switch. These operands are routed to the output operands if the control input is in the "On" position.
• 8BIT SW 1 CONTROL: This setting specifies FlexLogic operands to control the routing between the A and B inputs of
the switch. If the control operand is in the "Off" state, the first (A) input is switched to the output. If the control operand
is in the "On" state, the second (B) input is switched to the output. The switching takes place instantaneously.
 8-BIT
 SWITCH 1
8BIT SWITCH 1
FUNCTION: Disabled
Range: Disabled, Enabled
MESSAGE
8BIT SW 1 ARG A0:
Off
Range: FlexLogic operand
MESSAGE
8BIT SW 1 ARG A1:
Off
Range: FlexLogic operand
↓
MESSAGE
8BIT SW 1 ARG A7:
Off
Range: FlexLogic operand
MESSAGE
8BIT SW 1 ARG B0:
Off
Range: FlexLogic operand
MESSAGE
8BIT SW 1 ARG B1:
Off
Range: FlexLogic operand
↓
MESSAGE
8BIT SW 1 ARG B7:
Off
Range: FlexLogic operand
MESSAGE
8BIT SW 1 CONTROL:
Off
Range: FlexLogic operand
