GE C30 User Manual

GE Multilin C30 Controller System A-3
APPENDIX A A.1 PARAMETER LISTS
A
13599 RTD Inputs 48 Value --- RTD input 48 actual value
13600 Ohm Inputs 1 Value Ohms Ohm inputs 1 value
13601 Ohm Inputs 2 Value Ohms Ohm inputs 2 value
14189 PTP–IRIG-B Delta ns PTP time minus IRIG-B time
24447 Active Setting Group --- Current setting group
32768 Tracking Frequency Hz Tracking frequency
39168 FlexElement 1 Value --- FlexElement 1 actual value
39170 FlexElement 2 Value --- FlexElement 2 actual value
39172 FlexElement 3 Value --- FlexElement 3 actual value
39174 FlexElement 4 Value --- FlexElement 4 actual value
39176 FlexElement 5 Value --- FlexElement 5 actual value
39178 FlexElement 6 Value --- FlexElement 6 actual value
39180 FlexElement 7 Value --- FlexElement 7 actual value
39182 FlexElement 8 Value --- FlexElement 8 actual value
42336 PID 1 Out --- PID 1 out
42338 PID 1 Delta Out --- PID 1 delta out
42340 PID 1 Setpoint --- PID 1 setpoint
42342 PID 2 Out --- PID 2 out
42344 PID 2 Delta Out --- PID 2 delta out
42346 PID 2 Setpoint --- PID 2 setpoint
42348 PID 3 Out --- PID 3 out
42350 PID 3 Delta Out --- PID 3 delta out
42352 PID 3 Setpoint --- PID 3 setpoint
42354 PID 4 Out --- PID 4 out
42356 PID 4 Delta Out --- PID 4 delta out
42358 PID 4 Setpoint --- PID 4 setpoint
45584 GOOSE Analog In 1 --- IEC 61850 GOOSE analog input 1
45586 GOOSE Analog In 2 --- IEC 61850 GOOSE analog input 2
45588 GOOSE Analog In 3 --- IEC 61850 GOOSE analog input 3
45590 GOOSE Analog In 4 --- IEC 61850 GOOSE analog input 4
45592 GOOSE Analog In 5 --- IEC 61850 GOOSE analog input 5
45594 GOOSE Analog In 6 --- IEC 61850 GOOSE analog input 6
45596 GOOSE Analog In 7 --- IEC 61850 GOOSE analog input 7
45598 GOOSE Analog In 8 --- IEC 61850 GOOSE analog input 8
45600 GOOSE Analog In 9 --- IEC 61850 GOOSE analog input 9
45602 GOOSE Analog In 10 --- IEC 61850 GOOSE analog input 10
45604 GOOSE Analog In 11 --- IEC 61850 GOOSE analog input 11
45606 GOOSE Analog In 12 --- IEC 61850 GOOSE analog input 12
45608 GOOSE Analog In 13 --- IEC 61850 GOOSE analog input 13
45610 GOOSE Analog In 14 --- IEC 61850 GOOSE analog input 14
45612 GOOSE Analog In 15 --- IEC 61850 GOOSE analog input 15
45614 GOOSE Analog In 16 --- IEC 61850 GOOSE analog input 16
TABLE A–1: FLEXANALOG DATA ITEMS (Sheet 3 of 3)
ADDRESS FLEXANALOG NAME UNITS DESCRIPTION
