B-18 C30 Controller System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
3897 Remote Ground CT 1 Primary 1 to 65000 --- 1 F001 1
3898 Remote Ground CT 1 Secondary 0 to 1 --- 1 F123 0 (1 A)
3899 Remote Phase VT 1 Connection 0 to 1 --- 1 F100 0 (Wye)
389A Remote Phase VT 1 Secondary 25 to 240 --- 0.1 F001 664
389B Remote Phase VT 1 Ratio 1 to 24000 --- 1 F060 1
389D Remote Auxiliary VT 1 Connection 0 to 6 --- 1 F166 1 (Vag)
389E Remote Auxiliary VT 1 Secondary 25 to 240 --- 0.1 F001 664
389F Remote Auxiliary VT 1 Ratio 1 to 24000 --- 1 F060 1
38A1 ...Repeated for module number 2
38B2 ...Repeated for module number 3
38C3 ...Repeated for module number 4
38D4 ...Repeated for module number 5
38E5 ...Repeated for module number 6
Field Unit Contact Inputs (Read/Write Setting) (40 modules)
3900 Field Contact Input 1 ID --- --- 1 F205 "FCI 1"
3906 Field Contact Input 1 Origin 0 to 8 --- 1 F256 0 (None)
3907 Field Contact Input 1 Input 1 to 18 --- 1 F001 1
3908 Field Contact Input 1 Failsafe Value 0 to 1 --- 1 F108 0 (Off)
3909 Field Contact Input 1 Debounce Time 0 to 16 ms 0.5 F001 20
390A Field Contact Input 1 Events 0 to 1 --- 1 F102 1 (Enabled)
390B ...Repeated for Field Contact Input 2
3916 ...Repeated for Field Contact Input 3
3921 ...Repeated for Field Contact Input 4
392C ...Repeated for Field Contact Input 5
3937 ...Repeated for Field Contact Input 6
3942 ...Repeated for Field Contact Input 7
394D ...Repeated for Field Contact Input 8
3958 ...Repeated for Field Contact Input9
3963 ...Repeated for Field Contact Input 10
396E ...Repeated for Field Contact Input 11
3979 ...Repeated for Field Contact Input 12
3984 ...Repeated for Field Contact Input 13
398F ...Repeated for Field Contact Input 14
399A ...Repeated for Field Contact Input 15
39A5 ...Repeated for Field Contact Input 16
39B0 ...Repeated for Field Contact Input 17
39BB ...Repeated for Field Contact Input 18
39C6 ...Repeated for Field Contact Input 19
39D1 ...Repeated for Field Contact Input 20
39DC ...Repeated for Field Contact Input 21
39E7 ...Repeated for Field Contact Input 22
39F2 ...Repeated for Field Contact Input 23
39FD ...Repeated for Field Contact Input 24
3A08 ...Repeated for Field Contact Input 25
3A13 ...Repeated for Field Contact Input 26
3A1E ...Repeated for Field Contact Input 27
3A29 ...Repeated for Field Contact Input 28
3A34 ...Repeated for Field Contact Input 29
3A3F ...Repeated for Field Contact Input 30
3A4A ...Repeated for Field Contact Input 31
3A55 ...Repeated for Field Contact Input 32
3A60 ...Repeated for Field Contact Input 33
3A6B ...Repeated for Field Contact Input 34
3A76 ...Repeated for Field Contact Input 35
Table B–10: MODBUS MEMORY MAP (Sheet 10 of 48)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
