GE Multilin C30 Controller System B-25
APPENDIX B B.4 MEMORY MAPPING
B
42FF ...Repeated for User-Programmable LED 22
4302 ...Repeated for User-Programmable LED 23
4305 ...Repeated for User-Programmable LED 24
4308 ...Repeated for User-Programmable LED 25
430B ...Repeated for User-Programmable LED 26
430E ...Repeated for User-Programmable LED 27
4311 ...Repeated for User-Programmable LED 28
4314 ...Repeated for User-Programmable LED 29
4317 ...Repeated for User-Programmable LED 30
431A ...Repeated for User-Programmable LED 31
431D ...Repeated for User-Programmable LED 32
4320 ...Repeated for User-Programmable LED 33
4323 ...Repeated for User-Programmable LED 34
4326 ...Repeated for User-Programmable LED 35
4329 ...Repeated for User-Programmable LED 36
432C ...Repeated for User-Programmable LED 37
432F ...Repeated for User-Programmable LED 38
4332 ...Repeated for User-Programmable LED 39
4335 ...Repeated for User-Programmable LED 40
4338 ...Repeated for User-Programmable LED 41
433B ...Repeated for User-Programmable LED 42
433E ...Repeated for User-Programmable LED 43
4341 ...Repeated for User-Programmable LED 44
4344 ...Repeated for User-Programmable LED 45
4347 ...Repeated for User-Programmable LED 46
434A ...Repeated for User-Programmable LED 47
434D ...Repeated for User-Programmable LED 48
PRP Status (Read Only)
4363 Total Received Port A 0 to 4294967295 --- 1 F003 0
4365 Total Received Port B 0 to 4294967295 --- 1 F003 0
4367 Total Mismatches Port A 0 to 4294967295 --- 1 F003 0
4369 Total Mismatches Port B 0 to 4294967295 --- 1 F003 0
436B Total Errors 0 to 4294967295 --- 1 F003 0
IPv4 Route Table (Read/Write Setting) (6 modules)
4370 IPv4 Network Route 1 Destination 0 to 4294967295 --- 1 F003 2130706433
4372 IPv4 Network Route 1 Netmask 0 to 4294967295 --- 1 F003 4278190080
4374 IPv4 Network Route 1 Gateway 0 to 4294967295 --- 1 F003 2130706433
4376 ...Repeated for Route 2
437C ...Repeated for Route 3
4382 ...Repeated for Route 4
4388 ...Repeated for Route 5
438E ...Repeated for Route 6
Installation (Read/Write Setting)
43E0 Relay Programmed State 0 to 1 --- 1 F133 0 (Not
Programmed)
43E1 Relay Name --- --- --- F202 “Relay-1”
User Programmable Self Tests (Read/Write Setting)
4441 User Programmable Detect Ring Break Function 0 to 1 --- 1 F102 1 (Enabled)
4442 User Programmable Direct Device Off Function 0 to 1 --- 1 F102 1 (Enabled)
4443 User Programmable Remote Device Off Function 0 to 1 --- 1 F102 1 (Enabled)
4444 User Programmable First Ethernet Fail Function 0 to 1 --- 1 F102 0 (Disabled)
4445 User Programmable Secondary Ethernet Fail Function 0 to 1 --- 1 F102 0 (Disabled)
4446 User Programmable Battery Fail Function 0 to 1 --- 1 F102 1 (Enabled)
4447 User Programmable SNTP Fail Function 0 to 1 --- 1 F102 1 (Enabled)
Table B–10: MODBUS MEMORY MAP (Sheet 17 of 48)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
To Next Page
