GE Multilin C30 Controller System B-29
APPENDIX B B.4 MEMORY MAPPING
B
5858 ...Repeated for FlexLogic Timer 12
5860 ...Repeated for FlexLogic Timer 13
5868 ...Repeated for FlexLogic Timer 14
5870 ...Repeated for FlexLogic Timer 15
5878 ...Repeated for FlexLogic Timer 16
5880 ...Repeated for FlexLogic Timer 17
5888 ...Repeated for FlexLogic Timer 18
5890 ...Repeated for FlexLogic Timer 19
5898 ...Repeated for FlexLogic Timer 20
58A0 ...Repeated for FlexLogic Timer 21
58A8 ...Repeated for FlexLogic Timer 22
58B0 ...Repeated for FlexLogic Timer 23
58B8 ...Repeated for FlexLogic Timer 24
58C0 ...Repeated for FlexLogic Timer 25
58C8 ...Repeated for FlexLogic Timer 26
58D0 ...Repeated for FlexLogic Timer 27
58D8 ...Repeated for FlexLogic Timer 28
58E0 ...Repeated for FlexLogic Timer 29
58E8 ...Repeated for FlexLogic Timer 30
58F0 ...Repeated for FlexLogic Timer 31
58F8 ...Repeated for FlexLogic Timer 32
Disconnect (Breaker) Switch (Read/Write Setting) (8 modules)
74A0 Disconnect Switch 1 Function 0 to 1 --- 1 F102 0 (Disabled)
74A1 Disconnect Switch 1 Name --- --- --- F206 “SW 1"
74A4 Disconnect Switch 1 Mode 0 to 1 --- 1 F157 0 (3-Pole)
74A5 Disconnect Switch 1 Open 0 to 4294967295 --- 1 F300 0
74A7 Disconnect Switch 1 Block Open 0 to 4294967295 --- 1 F300 0
74A9 Disconnect Switch 1 Close 0 to 4294967295 --- 1 F300 0
74AB Disconnect Switch 1 Block Close 0 to 4294967295 --- 1 F300 0
74AD Disconnect Switch 1 Phase A / Three-pole Closed 0 to 4294967295 --- 1 F300 0
74AF Disconnect Switch 1 Phase A / Three-pole Opened 0 to 4294967295 --- 1 F300 0
74B1 Disconnect Switch 1 Phase B Closed 0 to 4294967295 --- 1 F300 0
74B3 Disconnect Switch 1 Phase B Opened 0 to 4294967295 --- 1 F300 0
74B5 Disconnect Switch 1 Phase C Closed 0 to 4294967295 --- 1 F300 0
74B7 Disconnect Switch 1 Phase C Opened 0 to 4294967295 --- 1 F300 0
74B9 Disconnect Switch 1 Operate Time 0 to 65.535 s 0.001 F001 70
74BA Disconnect Switch 1 Alarm Delay 0 to 65.535 s 0.001 F003 0
74BC Disconnect Switch 1 Events 0 to 1 --- 1 F102 0 (Disabled)
74BD Reserved (2 items) --- --- --- F001 0
74BF ...Repeated for Disconnect Switch 2
74DE ...Repeated for Disconnect Switch 3
74FD ...Repeated for Disconnect Switch 4
751C ...Repeated for Disconnect Switch 5
753B ...Repeated for Disconnect Switch 6
755A ...Repeated for Disconnect Switch 7
7579 ...Repeated for Disconnect Switch 8
Ohm Inputs (Read/Write Setting) (2 modules)
77F8 Ohm Inputs 1 Function 0 to 1 --- 1 F102 0 (Disabled)
77F9 Ohm Inputs 1 ID --- --- --- F205 "Ohm Ip 1 "
77FF Ohm Inputs 1 Reserved (9 items) 0 to 65535 --- 1 F001 0
7808 ...Repeated for Ohm Inputs 2
User Programmable Pushbuttons (Read/Write Setting) (16 modules)
7B60 User Programmable Pushbutton 1 Function 0 to 2 --- 1 F137 0 (Disabled)
7B61 User Programmable Pushbutton 1 Top Line --- --- --- F202 (none)
Table B–10: MODBUS MEMORY MAP (Sheet 21 of 48)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
