GE Multilin C30 Controller System B-31
APPENDIX B B.4 MEMORY MAPPING
B
EGD Slow Production Status (Read Only Non-Volatile and Read Only) (2 modules)
83F0 EGD Slow Producer Exchange 1 Signature 0 to 65535 --- 1 F001 0
83F1 EGD Slow Producer Exchange 1 Configuration Time 0 to 4294967295 --- --- F003 0
83F3 EGD Slow Producer Exchange 1 Size 0 to 65535 --- 1 F001 0
83F4 ...Repeated for EGD Slow Producer Exchange 2
EGD Fast Production (Read/Write Setting)
8400 EGD Fast Producer Exchange 1 Function 0 to 1 --- 1 F102 0 (Disabled)
8401 EGD Fast Producer Exchange 1 Destination 0 to 4294967295 --- 1 F003 0
8403 EGD Fast Producer Exchange 1 Data Rate 50 to 1000 ms 50 F001 1000
8404 EGD Fast Producer Exchange 1 Data Item 1 (20 items) 0 to 65535 --- 1 F001 0
8418 Reserved (80 items) --- --- --- F001 0
EGD Slow Production (Read/Write Setting) (2 modules)
8468 EGD Slow Producer Exchange 1 Function 0 to 1 --- 1 F102 0 (Disabled)
8469 EGD Fast Producer Exchange 1 Destination 0 to 4294967295 --- 1 F003 0
846B EGD Slow Producer Exchange 1 Data Rate 500 to 1000 ms 50 F001 1000
846C EGD Slow Producer Exchange 1 Data Item 1 (50 items) 0 to 65535 --- 1 F001 0
849E Reserved (50 items) --- --- --- F001 0
84D0 ...Repeated for EGD Exchange 2
FlexState Settings (Read/Write Setting)
8800 FlexState Parameters (256 items) 0 to 4294967295 --- 1 F300 0
Digital Elements (Read/Write Setting) (48 modules)
8A00 Digital Element 1 Function 0 to 1 --- 1 F102 0 (Disabled)
8A01 Digital Element 1 Name --- --- --- F203 “Dig Element 1“
8A09 Digital Element 1 Input 0 to 4294967295 --- 1 F300 0
8A0B Digital Element 1 Pickup Delay 0 to 999999.999 s 0.001 F003 0
8A0D Digital Element 1 Reset Delay 0 to 999999.999 s 0.001 F003 0
8A0F Digital Element 1 Block 0 to 4294967295 --- 1 F300 0
8A11 Digital Element 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
8A12 Digital Element 1 Events 0 to 1 --- 1 F102 0 (Disabled)
8A13 Digital Element 1 Pickup LED 0 to 1 --- 1 F102 1 (Enabled)
8A14 Reserved (2 items) --- --- --- F001 0
8A16 ...Repeated for Digital Element 2
8A2C ...Repeated for Digital Element 3
8A42 ...Repeated for Digital Element 4
8A58 ...Repeated for Digital Element 5
8A6E ...Repeated for Digital Element 6
8A84 ...Repeated for Digital Element 7
8A9A ...Repeated for Digital Element 8
8AB0 ...Repeated for Digital Element 9
8AC6 ...Repeated for Digital Element 10
8ADC ...Repeated for Digital Element 11
8AF2 ...Repeated for Digital Element 12
8B08 ...Repeated for Digital Element 13
8B1E ...Repeated for Digital Element 14
8B34 ...Repeated for Digital Element 15
8B4A ...Repeated for Digital Element 16
8B60 ...Repeated for Digital Element 17
8B76 ...Repeated for Digital Element 18
8B8C ...Repeated for Digital Element 19
8BA2 ...Repeated for Digital Element 20
8BB8 ...Repeated for Digital Element 21
8BCE ...Repeated for Digital Element 22
8BE4 ...Repeated for Digital Element 23
8BFA ...Repeated for Digital Element 24
Table B–10: MODBUS MEMORY MAP (Sheet 23 of 48)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
