B-54 C30 Controller System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
D35E IEC 61850 GGIO2.CF.SPCSO63.ctlModel Value 0 to 2 --- 1 F001 1
D35F IEC 61850 GGIO2.CF.SPCSO64.ctlModel Value 0 to 2 --- 1 F001 1
Remote Device Status (Read Only) (32 modules)
D380 Remote Device 1 StNum 0 to 4294967295 --- 1 F003 0
D382 Remote Device 1 SqNum 0 to 4294967295 --- 1 F003 0
D384 ...Repeated for Remote Device 2
D388 ...Repeated for Remote Device 3
D38C ...Repeated for Remote Device 4
D390 ...Repeated for Remote Device 5
D394 ...Repeated for Remote Device 6
D398 ...Repeated for Remote Device 7
D39C ...Repeated for Remote Device 8
D3A0 ...Repeated for Remote Device 9
D3A4 ...Repeated for Remote Device 10
D3A8 ...Repeated for Remote Device 11
D3AC ...Repeated for Remote Device 12
D3B0 ...Repeated for Remote Device 13
D3B4 ...Repeated for Remote Device 14
D3B8 ...Repeated for Remote Device 15
D3BC ...Repeated for Remote Device 16
D3C0 ...Repeated for Remote Device 17
D3C4 ...Repeated for Remote Device 18
D3C8 ...Repeated for Remote Device 19
D3CC ...Repeated for Remote Device 20
D3D0 ...Repeated for Remote Device 21
D3D4 ...Repeated for Remote Device 22
D3D8 ...Repeated for Remote Device 23
D3DC ...Repeated for Remote Device 24
D3E0 ...Repeated for Remote Device 25
D3E4 ...Repeated for Remote Device 26
D3E8 ...Repeated for Remote Device 27
D3EC ...Repeated for Remote Device 28
D3F0 ...Repeated for Remote Device 29
D3F4 ...Repeated for Remote Device 30
D3F8 ...Repeated for Remote Device 31
D3FC ...Repeated for Remote Device 32
Contact Outputs (Read/Write Setting) (64 modules)
DC90 Contact Output 1 Name --- --- --- F205 “Cont Op 1"
DC96 Contact Output 1 Operation 0 to 4294967295 --- 1 F300 0
DC98 Contact Output 1 Seal In 0 to 4294967295 --- 1 F300 0
DC9A Latching Output 1 Reset 0 to 4294967295 --- 1 F300 0
DC9C Contact Output 1 Events 0 to 1 --- 1 F102 1 (Enabled)
DC9D Latching Output 1 Type 0 to 1 --- 1 F090 0 (Operate-
dominant)
DC9E Reserved --- --- --- F001 0
DC9F ...Repeated for Contact Output 2
DCAE ...Repeated for Contact Output 3
DCBD ...Repeated for Contact Output 4
DCCC ...Repeated for Contact Output 5
DCDB ...Repeated for Contact Output 6
DCEA ...Repeated for Contact Output 7
DCF9 ...Repeated for Contact Output 8
DD08 ...Repeated for Contact Output 9
DD17 ...Repeated for Contact Output 10
Table B–10: MODBUS MEMORY MAP (Sheet 46 of 48)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
