GE C30

B-56 C30 Controller System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
DCmA Inputs (Read/Write Setting) (24 modules)
E050 DCmA Inputs 1 Function 0 to 1 --- 1 F102 0 (Disabled)
E051 DCmA Inputs 1 ID --- --- --- F205 “DCMA Ip 1"
E057 Reserved 1 (4 items) 0 to 65535 --- 1 F001 0
E05B DCmA Inputs 1 Units --- --- --- F206 “mA”
E05E DCmA Inputs 1 Range 0 to 6 --- 1 F173 6 (4 to 20 mA)
E05F DCmA Inputs 1 Minimum Value -9999.999 to 9999.999 --- 0.001 F004 4000
E061 DCmA Inputs 1 Maximum Value -9999.999 to 9999.999 --- 0.001 F004 20000
E063 ...Repeated for DCmA Inputs 2
E076 ...Repeated for DCmA Inputs 3
E089 ...Repeated for DCmA Inputs 4
E09C ...Repeated for DCmA Inputs 5
E0AF ...Repeated for DCmA Inputs 6
E0C2 ...Repeated for DCmA Inputs 7
E0D5 ...Repeated for DCmA Inputs 8
E0E8 ...Repeated for DCmA Inputs 9
E0FB ...Repeated for DCmA Inputs 10
E10E ...Repeated for DCmA Inputs 11
E121 ...Repeated for DCmA Inputs 12
E134 ...Repeated for DCmA Inputs 13
E147 ...Repeated for DCmA Inputs 14
E15A ...Repeated for DCmA Inputs 15
E16D ...Repeated for DCmA Inputs 16
E180 ...Repeated for DCmA Inputs 17
E193 ...Repeated for DCmA Inputs 18
E1A6 ...Repeated for DCmA Inputs 19
E1B9 ...Repeated for DCmA Inputs 20
E1CC ...Repeated for DCmA Inputs 21
E1DF ...Repeated for DCmA Inputs 22
E1F2 ...Repeated for DCmA Inputs 23
E205 ...Repeated for DCmA Inputs 24
DNP/IEC Points (Read/Write Setting)
E700 DNP/IEC 60870-5-104 Binary Input Points (256 items) 0 to 4294967295 --- 1 F300 0
E900 DNP/IEC 60870-5-104 Analog Input Points (256 items) 0 to 65535 --- 1 F300 0
Settings File Template (Read/Write Setting)
ED00 FlexLogic Displays Active 0 to 1 --- 1 F102 1 (Enabled)
ED01 Reserved --- --- --- F205 (none)
Setting File Template (Read Only Non-Volatile)
ED07 Last Settings Change Date 0 to 4294967295 --- 1 F050 0
Settings File Template (Read/Write Setting)
ED09 Template Bitmask (750 items) 0 to 65535 --- 1 F001 0
Table B–10: MODBUS MEMORY MAP (Sheet 48 of 48)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
