B-58 C30 Controller System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
F109
ENUMERATION: CONTACT OUTPUT OPERATION
0 = Self-reset, 1 = Latched, 2 = Disabled
F112
ENUMERATION: RS485 BAUD RATES
F113
ENUMERATION: PARITY
0 = None, 1 = Odd, 2 = Even
F114
ENUMERATION: IRIG-B SIGNAL TYPE
0 = None, 1 = DC Shift, 2 = Amplitude Modulated
F118
ENUMERATION: OSCILLOGRAPHY MODE
0 = Automatic Overwrite, 1 = Protected
F123
ENUMERATION: CT SECONDARY
0 = 1 A, 1 = 5 A
F124
ENUMERATION: LIST OF ELEMENTS
Bitmask Value Bitmask Value Bitmask Value
0 300 4 9600 8 115200
1 1200 5 19200 9 14400
2 2400 6 38400 10 28800
3 4800 7 57600 11 33600
Bitmask Element
336 Setting Group
337 Reset
388 Selector switch 1
389 Selector switch 2
390 Control pushbutton 1
391 Control pushbutton 2
392 Control pushbutton 3
393 Control pushbutton 4
394 Control pushbutton 5
395 Control pushbutton 6
396 Control pushbutton 7
400 FlexElement 1
401 FlexElement 2
402 FlexElement 3
403 FlexElement 4
404 FlexElement 5
405 FlexElement 6
406 FlexElement 7
407 FlexElement 8
420 Non-volatile Latch 1
421 Non-volatile Latch 2
422 Non-volatile Latch 3
423 Non-volatile Latch 4
424 Non-volatile Latch 5
425 Non-volatile Latch 6
426 Non-volatile Latch 7
427 Non-volatile Latch 8
428 Non-volatile Latch 9
429 Non-volatile Latch 10
430 Non-volatile Latch 11
431 Non-volatile Latch 12
432 Non-volatile Latch 13
433 Non-volatile Latch 14
434 Non-volatile Latch 15
435 Non-volatile Latch 16
536 8-bit Switch 1
537 8-bit Switch 2
538 8-bit Switch 3
539 8-bit Switch 4
540 8-bit Switch 5
541 8-bit Switch 6
544 Digital Counter 1
545 Digital Counter 2
546 Digital Counter 3
547 Digital Counter 4
548 Digital Counter 5
549 Digital Counter 6
550 Digital Counter 7
551 Digital Counter 8
692 Digital Element 1
693 Digital Element 2
694 Digital Element 3
695 Digital Element 4
696 Digital Element 5
697 Digital Element 6
698 Digital Element 7
699 Digital Element 8
700 Digital Element 9
701 Digital Element 10
702 Digital Element 11
703 Digital Element 12
704 Digital Element 13
705 Digital Element 14
706 Digital Element 15
707 Digital Element 16
708 Digital Element 17
709 Digital Element 18
710 Digital Element 19
711 Digital Element 20
712 Digital Element 21
Bitmask Element
