B-70 C30 Controller System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
F523
ENUMERATION: DNP OBJECTS 20, 22, AND 23 DEFAULT
VARIATION
F524
ENUMERATION: DNP OBJECT 21 DEFAULT VARIATION
F525
ENUMERATION: DNP OBJECT 32 DEFAULT VARIATION
F530
ENUMERATION: FRONT PANEL INTERFACE KEYPRESS
F531
ENUMERATION: LANGUAGE
0 = English, 1 = French, 2 = Chinese, 3 = Russian, 4 = Turkish
F600
UR_UINT16: FLEXANALOG PARAMETER
Corresponds to the Modbus address of the value used when this
parameter is selected. Only certain values can be used as FlexAn-
alogs (basically all metering quantities used in protection).
F601
ENUMERATION: COM2 PORT USAGE
F605
ENUMERATION: REMOTE DOUBLE-POINT STATUS INPUT
STATUS
F606
ENUMERATION: REMOTE DOUBLE-POINT STATUS INPUT
F611
ENUMERATION: GOOSE RETRANSMISSION SCHEME
F612
UR_UINT16: FLEXINTEGER PARAMETER
This 16-bit value corresponds to the Modbus address of the
selected FlexInteger parameter. Only certain values can be used
as FlexIntegers. There is no operation executed even though they
are called FlexIntegers.
Bitmask Default variation
01
12
25
36
Bitmask Default variation
01
12
29
310
Bitmask Default variation
01
12
23
34
45
57
Value Keypress Value Keypress Value Keypress
0 None 15 3 33 User PB 3
1 Menu 16 Enter 34 User PB 4
2 Message Up 17 Message
Down
35 User PB 5
37
~
18 0
~
36 User PB 6
4 8 19 Decimal 37 User PB 7
5 9 20 +/– 38 User PB 8
6 Help 21 Value Up 39 User PB 9
7 Message Left 22 Value Down 40 User PB 10
8 4 23 Reset 41 User PB 11
9 5 24 User 1 42 User PB 12
10 6 25User 2 44User 4
11 Escape 26 User 3 45 User 5
12 Message
Right
31 User PB 1 46 User 6
13 1 32 User PB 2 47 User 7
14 2
Enumeration COM2 port usage
0 RS485
1RRTD
2 GPM-F
3 RRTD and GPM-F
Enumeration Remote DPS input status
0 Intermediate
1Off
2On
3Bad
Enumeration Remote double-point status input
0None
1 Remote input 1
2 Remote input 2
3 Remote input 3
↓↓
64 Remote input 64
Enumeration Configurable GOOSE retransmission scheme
0 Heartbeat
1 Aggressive
2Medium
3 Relaxed
