C.7 LOGICAL NODES APPENDIX C
C
TPOS: Position indicator ---
TPRS: Pressure sensor ---
TRTN: Rotation transmitter ---
TSND: Sound pressure sensor ---
TTMP: Temperature sensor ---
TTNS: Mechanical tension ---
TVBR: Vibration sensor ---
TVTR: Voltage transformer ---
TWPH: Water acidity ---
X: LOGICAL NODES FOR SWITCHGEAR
XCBR: Circuit breaker Yes
XSWI: Circuit switch Yes
Y: LOGICAL NODES FOR POWER TRANSFORMERS
YEFN: Earth fault neutralizer (Petersen coil) ---
YLTC: Tap changer ---
YPSH: Power shunt ---
YPTR: Power transformer ---
Z: LOGICAL NODES FOR FURTHER POWER SYSTEM EQUIPMENT
ZAXN: Auxiliary network ---
ZBAT: Battery ---
ZBSH: Bushing ---
ZCAB: Power cable ---
ZCAP: Capacitor bank ---
ZCON: Converter ---
ZGEN: Generator ---
ZGIL: Gas insulated line ---
ZLIN: Power overhead line ---
ZMOT: Motor ---
ZREA: Reactor ---
ZRES: Resistor ---
ZRRC: Rotating reactive component ---
ZSAR: Surge arrestor ---
ZSCR: Semi-conductor controlled rectifier ---
ZSMC: Synchronous machine ---
ZTCF: Thyristor controlled frequency converter ---
ZTRC: Thyristor controlled reactive component ---
Table C–1: IEC 61850 LOGICAL NODES (Sheet 4 of 4)
