3-6
C30 Controller System
GE Multilin
3.1 DESCRIPTION
3 HARDWARE
3
Figure 3–7: C30 VERTICAL SIDE MOUNTI
NG REAR DIMENSIONS
(ST
ANDA
RD PANEL)
CUT-OUT
1.33"
(33.9)
2.83"
(71.9)
6.66"
(169.2)
12.20"
(309.9)
0.159" DIA. (6 PL
ACES)
(4.0)
0.213" DIA. (5.4)
(4 PLACES)
SEE HOLES MARKED 'X'
INCHES
MILLIMETERS
5.33"
(135.4)
PANEL SHOWN FOR
REFERENCE ONL
Y
(VIEWED FROM FR
ONT)
'X'
'X'
'X'
'X'
1.00"
(25.4)
1.00"
(25.4)
10.05
(255.3)
"
0.04
(1.0)
"
0.68"
(17.3)
5.27
(133.8)
"
843753A3.cdr
55
57
