GE Concord 4 Installation Manual

Appendix A: System planning sheets
114 Concord 4 Installation Manual
Part number Description Quantity mA (max.) Subtotal
60-983 ATP 1000 110 mA
60-984 ATP 2600 165 mA
60-985 ATP 2100 300 mA
600-1013 GTS 50 300 mA
60-836 Voice only module (with current jumper
installed) / (with current jumper removed)
300 mA /
600mA
60-777-01 Phone interface/voice module 600 mA
600-1019 2-amp power supply N/A
60-756 4 input/2 output SnapCard 185 mA
60-757 8Z hardwired zone expander SnapCard 230 mA
60-758 4 output SnapCard 130 mA
60-774 Hardwired input module 35 mA
60-770 Hardwired output module 180 mA
60-620-01 Energy saver module 20 mA
60-850
60-850-01
Cellular backup module (standard power)
Cellular backup module (high power)
10 mA
60-861 Wireless cellular gateway 1900 mA
60-677 Interrogator 200 audio verification module 1600 mA
60-783-02 Automation module 10 mA
60-528 Hardwired interior speaker 35 mA
13-060 15-watt speaker 500 mA
Total power consumption:
Total power consumption not to exceed:
mA
1,000 mA
* Total current only for all two-wire smoke detectors connected to panel two-wire smoke loop.

GE Concord 4 Specifications

General

Zones	96
Partitions	6
User Codes	230
Power Supply	16.5 VAC, 40 VA
Wireless Compatibility	Compatible with GE wireless sensors
Keypads	Up to 8
Outputs	2 onboard, expandable
Event Log	512 events
Backup Battery	12VDC, 7AH
Communication	Phone line, optional cellular or IP
