GE Concord 4 Installation Manual

Appendix B: Reference tables
136 Concord 4 Installation Manual
Response characteristics
Table 30 below describes the response characteristics.
Table 30: Response characteristics
Response characteristics Description
Momentary trip time The point remains active for nn seconds (n is 1 to 12 seconds). The
default is 4 seconds.
3-minute trip time The point remains active for 3 minutes.
Siren-time trip time The point remains active while the sirens are sounding.
Sustained trip time The point remains active for the duration of the event.
Siren pattern The point activates and deactivates according to the current alarm
type:
Auxiliary: fast on/off/on
Police: constant on
Fire: repeating
Trip delay The point activates 30 seconds after the trigger event occurs.
Response numbers
Table 31 below describes the response numbers.
Table 31: Response numbers
Response number Siren tracking Trip delay Response time
00 No No Momentary
01 No No 3 minutes [5]
02 No No Siren time [2]
03 No No Sustained [3]
04 No Yes [4] Momentary
05 No Yes [4] 3 minutes [5]
06 No Yes [4] Siren time [2]
07 No Yes [4] Sustained [3]
08 Yes [1] No Momentary
09 Yes [1] No 3 minutes [5]
10 Yes [1] No Siren time [2]

GE Concord 4 Specifications

General

Zones	96
Partitions	6
User Codes	230
Power Supply	16.5 VAC, 40 VA
Wireless Compatibility	Compatible with GE wireless sensors
Keypads	Up to 8
Outputs	2 onboard, expandable
Event Log	512 events
Backup Battery	12VDC, 7AH
Communication	Phone line, optional cellular or IP
