GE Concord 4 Installation Manual

Chapter 2: Installation
8 Concord 4 Installation Manual
Table 4: Wire length requirements
Device Max. wire
length to panel
Standby mA
draw
Alarm mA draw
SuperBus 2000 2x16 LCD alphanumeric
touchpad
22 ga.: 300 ft.
18 ga.: 750 ft.
15 mA 90 mA
SuperBus 2000 ATP 1000 alphanumeric
touchpad
22 ga.: 300 ft.
18 ga.: 750 ft.
12 mA 110 mA
SuperBus 2000 ATP 2100 alphanumeric
touchpad
22 ga.: 300 ft.
18 ga.: 750 ft.
30 mA 165 mA
SuperBus 2000 ATP 2600 alphanumeric
touchpad
22 ga.: 300 ft.
18 ga.: 750 ft.
30 mA 165 mA
SuperBus 2000 fixed display touchpad 22 ga.: 300 ft.
18 ga.: 700 ft.
11 mA 65 mA
SuperBus 2000 FTP 1000 fixed display touchpad 22 ga.: 300 ft.
18 ga.: 700 ft.
12 mA 75 mA
SuperBus 2000 RF transceiver 22 ga.: 1,000 ft.
18 ga.: 2,500 ft.
45 mA 55 mA
SuperBus 2000 phone interface/voice module 22 ga.: 40 ft.
18 ga.: 120 ft.
25 mA 600 mA
SuperBus 2000 voice-only module 22 ga.: 40 ft.
18 ga.: 120 ft.
20 mA 300 mA (jumper)
600 mA (no
jumper)
SuperBus 2000 2 amp power supply No load No load
4 input/2 output SnapCard N/A 20 mA 185 mA*
8Z hardwired zone expander SnapCard N/A 38 mA 230 mA*
4 output SnapCard N/A 1 mA 130 mA*
SuperBus 2000 8Z input module 22 ga.: 1,800 ft.
18 ga.: 4,000 ft.
18 mA 35 mA
SuperBus 2000 4-relay output module 22 ga.: 350 ft.
18 ga.: 900 ft.
12 mA 180 mA
SuperBus 2000 energy saver module 22 ga.: 1,600 ft.
18 ga.: 4,000 ft.
20 mA 20 mA
SuperBus 2000 automation module 22 ga.: 1,500 ft.
18 ga.: 4,000 ft.
30 mA 35 mA
SuperBus 2000 wireless cellular gateway 22 ga.: 40 ft.
18 ga.: 90 ft.
65 mA 1600 mA
Interrogator 200 22 ga.: 3,200 ft.
18 ga.: 4,500 ft.
10 mA 10 mA
Interrogator AVM 22 ga.: 110 ft.
18 ga.: 260 ft.
45 mA 300 mA

GE Concord 4 Specifications

General

Zones	96
Partitions	6
User Codes	230
Power Supply	16.5 VAC, 40 VA
Wireless Compatibility	Compatible with GE wireless sensors
Keypads	Up to 8
Outputs	2 onboard, expandable
Event Log	512 events
Backup Battery	12VDC, 7AH
Communication	Phone line, optional cellular or IP
