GE Concord 4 Installation Manual

Chapter 3: Programming
Concord 4 Installation Manual 41
SnapCards
Output programming
Output 1
Partition assign (101100) [1]
Configuration (101101) [01400]
Output 2
Partition assign (101110) [1]
Configuration (101111) [00410]
Output 3
Partition assign (101120) [1]
Configuration (101121) [00903]
Output 4
Partition assign (101130) [1]
Configuration (101131) [01003]
Output text
Output 1 (10120)
Output 1 item n
Output 2 (10121)
Output 2 item n
Output 3 (10122)
Output 3 item n
Output 4 (10123)
Output 4 item n
Inputs
Smoke verify (1100) [Off]
Two-wire smoke (1101) [Off]
Onboard
options
Output programming
Output 1
Partition assign (11100) [1]
Configuration (11101) [01614]
Output 2
Partition assign (11110) [1]
Configuration (11111) [01710]
Output text
Output 1 (1120)
Output 1 item n
Output 2 (1121)
Output 2 item n

GE Concord 4 Specifications

General

Zones	96
Partitions	6
User Codes	230
Power Supply	16.5 VAC, 40 VA
Wireless Compatibility	Compatible with GE wireless sensors
Keypads	Up to 8
Outputs	2 onboard, expandable
Event Log	512 events
Backup Battery	12VDC, 7AH
Communication	Phone line, optional cellular or IP
