Chapter 3: Programming
76 Concord 4 Installation Manual
Onboard options - output programming settings
Output 1, 2
Shortcuts:
11100 (output 1ptn)
11101 (configuration);
11110 (output 2 ptn),
11111 (configuration)
Default:
Ptn 1, 01614 (output 1)
Ptn 1, 01710 (output 2)
This setting assigns the partition and the five-digit configuration number for
the two onboard outputs. The configuration number determines:
• Which system event activates the selected output.
• The duration or time the output is activated.
The first three digits represent the trigger number of an event (such as
triggering an alarm, opening a sensor, or arming the system). The last two
digits represent how the output responds, For example, momentary
switching, maintained (or latched) switching, or switching for a preset time.
Note: If you want to configure an output for user output control you must
use the output text feature to name the output. If no output text is
programmed, user output control will not function for that output.
Use the system event trigger and response numbers listed in
Table 31 on
page 136.
To set up onboard output 1 and 2 partition and configuration assignments:
1. With the display showing ONBOARD OPTIONS, press #, B. The display
shows OUTPUT PROGRAMMING.
2. Press # and the display shows OUTPUT 1. Press B to select output 2.
3. Press # and the display shows PARTITION ASSIGN n (current
setting).
4. Press 1 to 6 to assign the output to the desired partition, then press #. The
display shows PARTITION ASSIGN (new setting).
5. Press B and the display shows CONFIGURATION tttrr (current
setting).
6. Enter the configuration number. The display flashes the entered number.
Press # and the display shows the new setting.
7. Press # and repeat the process until all outputs are programmed.
