Chapter 3: Programming
88 Concord 4 Installation Manual
Energy saver menu
The Energy saver menu lets you set the energy saver module or dialog RF thermostat
low- and high-setpoints. These setpoints override the premises thermostat allowing
the energy saver module or dialog RF thermostat to activate the furnace/air
conditioner.
Low setpoint
Shortcut: 070
Default: 50°F
This setting determines the temperature at which the energy saver module
relay closes to activate the furnace. The low setpoint cannot be set equal to
or higher than the high setpoint. Enter the desired temperature (45 to 89°F).
High setpoint
Shortcut: 071
Default: 90°F
This setting determines the temperature at which the energy saver module
relay closes to activate the air-conditioner. The high setpoint cannot be set
equal to or lower than the low setpoint. Enter the desired temperature (46 to
90°F).
Attach lights to sensors menu
This menu lets you assign a light number to a sensor. Each time the sensor is
activated, the attached light will turn on for 5 minutes. When the 5-minute timer
expires, the light will turn off. If the same light is scheduled, it will only turn on during
the schedule time.
Light X to Sensor Y
Shortcut: 08n where n is
light number minus 1
Default: 0
This menu attaches light x to sensor y. Each time a selected sensor is
tripped, the selected light will turn on and a 5-minute timer will start. The
sensor must be learned into the current partition before it can be attached.
To attach a light to a sensor:
1. With the display showing LIGHT 1 TO SENSOR y (current setting),
press A or B to select the light number.
2. Enter the sensor number (01 to 96). The display flashes the entered
setting. Press # and the display shows the new setting.
3. Repeat the process until all desired lights are attached to sensors.
To detach a light from a sensor:
1. With the display showing LIGHT 1 TO SENSOR y (current setting),
press A or B to select the light number.
2. Enter 0 as the sensor number and press #.
