Chapter 2. Initial Setup
26 DigitalFlow™ GF868 Startup Guide (1 and 2-Channel)
2.5.3 1- and 2-Channel Meters (cont.)
4. Use the [F1]-[F4] and [] keys to select the Totalizer Units.
The abbreviations and definitions of all the available volumetric and totalizer units are shown in Table 2-2 on the
previous page. The choices shown on the option bar in the prompt screen above are determined by the selection made
at the previous SYSTEM UNITS prompt screen.
5. Use the [F1]-[F4] keys to select the Total Decimal Digits (the desired number of digits to the right of the decimal
point) in the totalized flow display.
6. Use the [F1]-[F4] keys to select the Mass Flow units, listed in Table 5.
7. Use the
[F1]-[F4] keys to select the Mass Flow Time units.
8. Use the [F1]-[F4] keys to select the MDOT DECIMAL DIGITS (the number of digits to the right of the decimal
point) for displaying mass flow.
9. Use the [F1]-[F4] keys to select the Mass (Totalizer) units, listed in Table 5 above.
10. .Use the [F1]-[F4] to specify the Mass Decimal Digits (the number of digits to the right of the decimal point) for
displaying totalized mass flow. The meter returns to the initial User (or Channel) Program screen.
Proceed directly to the next section to program the PIPE submenu.
Table 5: Available Mass Flow Units
English Mass Flow Units Metric Mass Flow Units
LB- Pounds KG - Kilograms
KLB - Thousands of Pounds
MMLB - Millions of Pounds
TONS -Tons Tonnes - Metric Tons
