Chapter 1. Installation
DigitalFlow™ XMT868i Startup Guide 25
1 2 3
FIELDBUS NET (+)
FIELDBUS NET (–)
SHIELD (OPTIONAL)
J8
1 2 3
N/C
FACTORY RESET
RTN
J9
1 2 3
COM
RX
TX
J6
ETHERNET
(RJ45)
TB6
ETHERNET
(RJ45)
(a)
ETHERNET
Terminal Block Connector
(b)
FOUNDATION FIELDBUS
Terminal Block Connector
(c)
MODBUS/TCP
Terminal Block Connector
Figure 12: Ethernet, Foundation Fieldbus and MODBUS/TCP Terminal Block Connections
