Chapter 7. Specifications
DM5E Operating Manual 61
7.3 DM5E Probe/Transducer Specifications
Model DA501 Model DA503 Model DA512 Model DA590
Frequency: 5 MHz 2 MHz 10 MHz 5 MHz
Probe Style: standard standard fingertip high-temperature
Operating Temperature
Range (continuous):
-10 to 70°C -10 to 70°C -10 to 70°C -10 to 204°C
Contact Diameter: 15 mm (.590”) 20 mm (.787”) 7.5 mm (.300”) 12.7 mm (.500”)
IP to First
Measurement Range:
1.0 to 200 mm
(.040 to 8”)
5 to 300 mm
(.200 to 12”)
0.6 to 60 mm
(.020 to 2.4”)
1 to 125 mm @20°C
(.040 to 5” @68°F)
1.3 to 25.4 mm @204°C
(.050 to 1” @400°F)
Minimum Multi-Echo
Measurement Range:
3.0 to 25 mm N/A 2.0 to 10 mm N/A
