Chapter 1 Installation Procedure
1 PIST0002 - Prepare Floor - LC Base Plate and Omega/Innova IQ Table
1.1 Personnel Requirements
Personnel
Requirements
Preliminary Reqs Procedure Finalization
1 0 min 1 hour 0 min
1.2 Overview
This direction describes the hospital exam room floor preparation required prior to installing an LC
Gantry and an Omega/Innova
IQ
Table. Mylar floor drilling template is needed. The floor preparation
process consists of drilling LC Gantry (12) holes and Omega Table (4) holes or Innova
IQ
Table
(10) mounting holes in the floor so that as the equipment arrives on–site, the installation crew can:
•
Pour a grout pad for the LC Gantry around the pre–drilled mounting holes.
•
Mount and anchor the LC Gantry Base plate and Omega/Innova
IQ
Table baseplate to the floor.
•
Mount the LC Gantry.
•
Mount the Omega or Innova
IQ
Table with the correct alignment to the gantry (Isocenter aligned
and proper clinical usage distance between gantry and table).
NOTE: The preferred method of gantry/table floor mounting is the anchored bigplate supporting
the LC and the table, or else using through bolts. This method has been pre–approved
for use in all seismic zones. If the floor structure prevents using through–bolts, floor
anchors may be used. Through–bolt hardware and anchors are provided to the
installation crews before/with the equipment delivery.
1.3 Preliminary Requirements
1.3.1 Tools and Test Equipment
Item Qty Effectivity Part# Manufacturer
Carbide–tipped drill bit for
installing gantry and table
anchors: ANSI B94.12 or
5/8” for on–grade above
anchors
1 - - -
Carbide–tipped drill bit for
installing gantry and table
through bolts: 25 mm (1”)
recommended,
1 - - -
Single Plane and Biplane Innova Systems Pre–Installation Kit Installation Procedures
GE Healthcare Direction 2290880-12-1EN, Revision 1
Chapter 1 Installation Procedure 15
