2 PIST0003 - Vascular Gantry Base Plate and Innova IQ Table Base Plate
2.1 Personnel Requirements
Personnel
Requirements
Preliminary Reqs Procedure Finalization
1 0 min 2 hours 0 min
2.2 Overview
2.3 Preliminary Requirements
2.3.1 Tools and Test Equipment
Item Qty Effectivity Part# Manufacturer
Torque wrench, 150 ft-lbs
(20 daN.m)
1 - - -
Hammer for tapping in floor
anchors
1 - - -
1” wire brush for cleaning out
table anchor holes
1 - - -
(1-1/4”) 30 mm open end
wrench for (3/4”) 20 mm nuts
1 - - -
(1-1/4”) 30 mm socket for
(3/4”) 20 mm bolts
1 - - -
15/16” torque wrench socket 1 - - -
Vacuum cleaner 1 - - -
2.3.2 Consumables
Item Qty Effectivity Part# Manufacturer
Base Plate Assembly 1 - 2285048 -
Elegance Add–on kit 1 - 2360538 -
Above grade, Floor anchors
without insert
1 - 2285051 -
Through bolts without insert 1 - 2285646 -
On grade, Floor anchors 1 - 2286398 -
Above grade, Floor anchors
and insert
1 - 2285052 -
Through bolts and insert 1 - 2285053 -
Single Plane and Biplane Innova Systems Pre–Installation Kit Installation Procedures
GE Healthcare Direction 2290880-12-1EN, Revision 1
20 2 PIST0003 - Vascular Gantry Base Plate and Innova IQ Table Base Plate
