– 57 –
Oven - JB968 and JB988
VIEW
NUMBER
CATALOG NUMBER DESCRIPTION QUANTITY USED ON
20 WB02T10194 BRACKET CAPACITOR 1
66 WB34T10083 ENCLOSURE RANGETOP 1
92 WB02T10067 GROUND STRAP 1
94 WB02T10132 BRACE CHASSIS (RAD) 1 JB988 ONLY
94 WB02T10133 BRACE CHASSIS (RAD) 1 JB968 ONLY
136 WB15K10039 DRAWER HANDLE (BLK) 1
146 WB02X9037 DOOR HANDLE SPACER-BLACK 6
201 WB63T10099 BODY OVEN WELD ASM 1
202 WB63T10054 FRONT FRAME 1
203 WB63T10047 MAIN BACK 1
204 WB55T10046 STORAGE DRAWER LINING 1
211 WB02T10028 SIDE INSULATION RETAINER 2
217 WB34T10012 BACK COVER 1
219 WB34T10011 RECEPTICLE COVER 1
221 WB63T10051 BODY SIDE/BLACK 2
222 WB56T10124 PANEL DRAWER 1
227 WB02T10196 WIRE INSLN OVN 1
229 WB35T10017 VENT TUBE INSULATION 1
229 WB35T10087 INSULATION CONV. 1
231 WB35T10093 INSULATION OVEN 1
232 WB35T10023 OVN BACK/BTM INSULATION 1
