GE JT5000 Technical Service Guide

62
GE Title or job number
11/26/2013
Troubleshooting- Upper or single convection -
120 volt circuits
Light circuit CN600-5 BK to CN600-7 BR approx. 18Ω
Convection fan motor CN650-2 BL to TB101 W approx.
30Ω
Latch motor CN600-1 GY/BK to TB101 W approx.
1.8KΩ NOTE: door has to be closed*
Cooling fan motor LOW CN600-3 BK/W to TB101
approx. 25Ω. NOTE: 15Ω IF DWO - as there are 2
motors in parallel
