67
GE Title or job number
11/26/2013
Machine Control - upper/single
J700
Communications
J300 oven
sensor
Meat probe
J900 door
switches
Upper FAD board
J801 Lights, cooling fan, convection fan
Common NEUTRAL J102
J803 conv.
J804 outer broil
J101
ground
Broil Bake
L2-DLB
Back to definitions. Back to T of C
Located behind control panel on floor 1 -1/4” screw secures board to air duct.
