Quick Start 7
LOGIQ
t
200PRO Series Quick Start
2234974–100 Rev. 0
Starting an Exam
Patient Entry Menu
Press New Patient key at the beginning of each patient study to reset the system and enter new
patient data. When the New Patient key is pressed, the Patient Entry menu appears.
Use the Trackball to move the highlight cursor to the Exam
Category Selection line. Enter the desired exam number and fill in
the appropriate patient data.
Highlight EXIT and press Return or press New Patient again when
the patient entry menu data has been completed.
The system takes a few seconds to load new exam category
parameters and calibrate the attached transducers before entering
the scan mode.
New Patient
[ PATIENT ENTRY MENU ]
EXAM CATEGORY SELECTION : 1
1: RAD/ABDOMEN 2: OBSTETRICS 3: GYNECOLOGY
4: CARDIOLOGY 5: UROLOGY 6: SMALL PARTS
7: USER DEFINE1 8: USER DEFINE2
PT NAME :
PT ID :
NOTE :
Oper ID :
EXAM INFORMATION
AGE: yrs
Ref MD:
COMMENT :
EXIT
To Next Page
