Quick Start 18
LOGIQ
t
200PRO Series Quick Start
2234974–100 Rev. 0
Performing Basic Measurements
Basic measurements are displayed on the monitor and not automatically entered into a report page unless a specific
measurement/calculation is selected from the sub–menu. The specific measurement/calculation can be chosen before or
after the basic measurement has been performed.
Scan the desired anatomy and press Freeze.
Press Measurement key. Type of the measurement can be chosen by pressing the
Measurement key.
MODE
Key Pressed
(After Freeze key is pressed)
B M
(with B)
Once Distance
Ellipse
Tissue Depth
Tissue Depth
(Distance)
Depth Difference
Twice Trace/Circle Time Interval
Three Times Gray Scale Echo Level Time Slope
Measurement
To Next Page
