200PRO Series Quick Start
2234974–100 Rev. 0
Body Patterns
Body patterns are a simple graphic of a portion of the anatomy that is frequently scanned.
Press the Body Pattern key to activate Body Patterns.
A body pattern, generally displayed in the lower left corner of the screen, appears.
Cycle through the body patterns by pressing the Body Pattern key
repeatedly.
A Probe Orientation Marker is used to illustrate the probe position.
This marker can be placed with the Trackball and rotated
with the Rotation/Focus control. Press Set to complete
the body pattern selection.
Body Pattern
Focus Rotation
ECG Gain
Probe Orientation
Marker
To Next Page
