Quick Start 12
LOGIQ
t
200PRO Series Quick Start
2234974–100 Rev. 0
M-Mode Controls
Since M-Mode is basically a single B-Mode scan vector displayed over time, basic controls that affect the B-Mode display
also affect the M-Mode display. See
Quick Start 9
for comments on these controls.
TGC and Depth affect both the M-Mode and B-Mode displays.
If the scan area size is reduced and the position changed, the M-Mode cursor will follow the position change to stay within
the displayed scan area.
The Dual Format keys work the same as in dual B-Mode, but both B-Mode and M-Mode are displayed on the left and right
sides of the screen.
The keyboard controls that effect M-Mode are as follows:
M-Mode Optimization
Adjustments for... Do the Following... Adjustments for... Do the Following...
Improve M-Mode
1. Increase/decrease B/M GAIN.
2. Increase Dynamic Range.
Increase Size of Area
of Interest
1. Use M-Mode ZOOM.
To Next Page
