Quick Start 14
LOGIQ
t
200PRO Series Quick Start
2234974–100 Rev. 0
Reviewing Cine Images
To display cine images:
Press the Freeze key to stop image acquisition.
When Freeze is activated, rotate the cine Scroll control to display individual image frames which
were stored by the system.
NOTE: Cine frame number is the most current image. The lower the cine frame number, the
older the image. The dynamic range and gain parameters displayed on the screen are valid for
cine frame number zero only.
NOTE: One click of the Cine Scroll knob erases displayed measurements.
Cine Scroll
B.M.Gain
FWBW
