GE HEALTHCARE
DIRECTION 5162630, REVISION 3 LOGIQ™ S6 SERVICE MANUAL
Section 8-3 - Software Loading Procedures (R7.7.x or later with BEP4) 8-39
8-3-10-1 Confirmation of the software version (cont’d)
2.) Touch the System button on the Touch Panel.
3.) Click on About tab. The software version will be shown on the monitor as shown. Confirm the
following:
- Software Version (R
7.7.x)
- Preset Region (Americas, Europe, Asia, Japan, or None)
- Image Part Number (described on the Base System Software Image DVD)
Figure 8-156 System
NOTICE
For Upgraded BT08, this shall remain NONE.
Figure 8-157 About
Press System
button.
Click on the About tab
Software Version
R 7.7.x
Base System Software CD-ROM
Part Number
xxxxxxx
Preset Region
To Next Page
