GE HEALTHCARE
DIRECTION 5162630, REVISION 3 LOGIQ™ S6 SERVICE MANUAL
8-58 Section 8-3 - Software Loading Procedures (R7.7.x or later with BEP4)
8-3-10-8 Printer Registration
1.) Verify that the power switches of the printer and scanner are turned ON.
2.) Select Utility > Connectivity > Button.
3.) Select the Printer1 button and select the user defined printer which has been recorded in 1-5-7
Printer Registration.
4.) Click on >> to add Printflow View.
Figure 8-180 Printer Setting Screen
1. Select the
button the
SONY UP-
D23MD
should be
assigned.
2. Select the user defined printer.
3. Click on >>.
To Next Page
