GE HEALTHCARE
DIRECTION 5162630, REVISION 3 LOGIQ™ S6 SERVICE MANUAL
9-12 Section 9-5 - Renewal Parts List for Original LOGIQ S6 (BT06)
Table 9-75 Plastic Covers
Item Part Name Part Number Description Qty FRU
1 REAR HANDLE 5170162 1 2
2 CONSOLE TOP COVER ABS 5171964 without tapping screw 1 2
3 REAR COVER ASSY L6 5170246 China and Korea are exluded. 1 2
4 REAR DOOR COVER ASSY L6 5168993 1 2
5 SIDE FRINGE 2303896 1 2
6 CONSOLE SIDE CAP ABS 2301527 1 2
7 KBD Bottom Cover 2301529 without bottom curtain, same composition as LOGIQ5 1 2
8 OP FRONT BUMPER L6 5168868 1 2
9 OP PROBE HOLDER L6 5175882 without gel holder 1 2
10 FRONT COVER ASSY L6 5168957 1 2
11 FRONT BASE COVER ASSY L6 5170181 1 2
12 SIDE COVER R ASSY L6 5169002 1 2
13 SIDE COVER L ASSY L6 5168881 1 2
14 OP SIDE R COVER ABS 5170142 1 2
15 OP SIDE L COVER ABS 2301532 1 2
16 OP REAR COVER2 ABS GE GRAY 2371537 For Standard 1 2
17 CWD BRACKET L6 5147526 1 2
18 ECG CABLE HOOK 2283028 1 2
19 OP SIDE DUMMY COVER ABS 2301531 1 2
20 BLOCK GEL WARMER POWER CAP 2328024 1 2
21 Front Bottom Curtain Short 2374267 without plate (for standard) 1 2
22 Front Bottom Curtain Long 5162514 without plate (for tall) 1 2
23 GEL HOLDER L6 5168986 1 2
24 OP REAR COVER TALL L6 5162515 For Tall 1 2
25 PROBE HOLDER BRACKET L6 5147525-2 1 2
To Next Page
