DIRECTION 5162630, REVISION 3 LOGIQ™ S6 SERVICE MANUAL
Section 4-2 - General Procedure 4-15
4-2-6-2 Archiving Presets to an MO/DVD-R Disk
1.) Insert an empty (blank) formatted MO/DVD-R disk into the MO/DVD-R device.
2.) Access to the Utility Menu on the Touch Panel, and select System>Backup/Restore. The Backup
screen will be shown on the monitor.
3.) Select the item to back up either from Resource Files.
4.) Select the media to locate the items.
5.) Click on Backup. The backup status for each item is displayed on the Result column.
6.) Make sure “Finished OK” is displayed on the Result column.
Figure 4-26 Backup Sheet
