CHAPTER 1: OVERVIEW
EPM 6000 MULTI-FUNCTION POWER METERING SYSTEM – USER GUIDE 1–5
1.3 Ordering
1.3.1 Order Codes
The order codes for the EPM 6000 are indicated below.
For example, to order an EPM 6000 for 60 Hz system with a 1 A secondary CT input and no
THD or pulse output option, select order code PL6000-6-1A-0. The standard unit includes
display, all current/voltage/power/frequency/energy counters, percent load bar, RS485,
and IrDA communication ports.
Table 1–2: EPM 6000 Order Codes
PL6000 – * – * – *
Base Unit
PL6000 || |
EPM 6000 Power Metering System
System
Frequency
5 | |
50 Hz AC frequency system
6 | |
60 Hz AC frequency system
Current Input
1A |
1 A secondary CT
5A |
5 A secondary CT
THD and Pulse Output
0
No THD or pulse output option
THD
THD, limit alarms, and 1 KYZ pulse output
