CHAPTER 3: INSTALLATION

EPM 6000 MULTI-FUNCTION POWER METERING SYSTEM – USER GUIDE 3–3

FIGURE 3–3: ANSI Mounting Procedure

3.1.3 DIN Installation Steps

Mount the meter in a dry location free from dirt and corrosive substances. The meter is

designed to withstand harsh environmental conditions (see the Environmental

specifications in Chapter 2 for additional details).

Use the following steps to install the meter:

Z Slide the meter with NEMA 12 mounting gasket into panel.

NEMA12 mounting

gasket

threaded rods

lock washer

and nut
