VLAN CHAPTER 10: VLAN
Example 10-1: Converting Port VLAN to Tag VLAN
ML1200#vlan type=port
ML1200(port-vlan)##show vlan type=port
VLAN ID: 1
Name : Default VLAN
Status : Active
========================
PORT | STATUS
========================
5 | DOWN
6 | DOWN
7 | UP
VLAN ID: 10
Name : engineering
Status : Active
========================
PORT | STATUS
========================
1 | DOWN
VLAN ID: 20
Name : sales
Status : Active
========================
PORT | STATUS
========================
2 | DOWN
VLAN ID: 30
Name : marketing
Status : Active
========================
PORT | STATUS
========================
3 | DOWN
VLAN ID: 40
Name : Support
Status : Active
========================
PORT | STATUS
========================
4 | UP
ML1200(port-vlan)##
stop vlan=all
All active VLAN's stopped.
ML1200(port-vlan)##exit
ML1200#set vlan type=tag
VLAN set to Tag-based.
ML1200#show active-vlan
Tag VLAN is currently active.
ML1200#show vlan type=tag
(Continued on next page)
To switch to Tag VLAN, the port VLAN has to be disabled or
stopped. Only one type of VLAN can co-exist at the same
time. Exit out of Port VLAN configuration mode and set the
VLAN type to be Tag VLAN.
