Converting Port VLAN to Tag VLAN (continued)
VLAN ID: 1
Name : Default VLAN
Status : Active
-----------------------------------------------
PORT | MODE | STATUS
-----------------------------------------------
1 | UNTAGGED | UP
2 | UNTAGGED | DOWN
3 | UNTAGGED | DOWN
4 | UNTAGGED | DOWN
5 | UNTAGGED | DOWN
6 | UNTAGGED | DOWN
7 | UNTAGGED | UP
ML1200#
vlan type=tag
ML1200(tag-vlan)##add id=10 name=mkt port=3-5
Tag based vlan Added Successfully.
Vlan id :10
Vlan name : engineering
Ports :3-5
ML1200(tag-vlan)##
edit id=10 name=engineering port=3-5
Tag based vlan edited Successfully.
Vlan id : 10
Vlan name : engineering
Ports : 3-5
ML1200(tag-vlan)##
add id=20 name=sales port=3-5
Tag based vlan Added Successfully.
Vlan id :20
Vlan name : sales
Ports :3-5
ML1200(tag-vlan)##
add id=20 name=marketing port=3-5
ERROR: Duplicate Vlan Id
ML1200(tag-vlan)##add id=30 name=marketing port=3-5
Tag based vlan Added Successfully.
Vlan id :30
Vlan name : marketing
Ports :3-5
ML1200(tag-vlan)##
show vlan type=tag
(continued on next page)
Note that ports 3 to 5 are “DOWN” - the
VLAN configuration is preferably done
before devices are plugged in to avoid
connectivity repercussions.
Intentionally executed to
show the effect of adding a
duplicate VLAN.
