Converting Port VLAN to Tag VLAN (continued)
VLAN ID: 1
Name : Default VLAN
Status : Active
-----------------------------------------------
PORT | MODE | STATUS
-----------------------------------------------
1 | UNTAGGED | UP
2 | UNTAGGED | DOWN
3 | UNTAGGED | DOWN
4 | UNTAGGED | DOWN
5 | UNTAGGED | DOWN
6 | UNTAGGED | DOWN
7 | UNTAGGED | UP
VLAN ID: 10
Name : engineering
Status : Pending
-----------------------------------------------
PORT | MODE | STATUS
-----------------------------------------------
3 | UNTAGGED | DOWN
4 | UNTAGGED | DOWN
5 | UNTAGGED | DOWN
VLAN ID: 20
Name : sales
Status : Pending
-----------------------------------------------
PORT | MODE | STATUS
-----------------------------------------------
3 | UNTAGGED | DOWN
4 | UNTAGGED | DOWN
5 | UNTAGGED | DOWN
VLAN ID: 30
Name : marketing
Status : Pending
-----------------------------------------------
PORT | MODE | STATUS
-----------------------------------------------
3 | UNTAGGED | DOWN
4 | UNTAGGED | DOWN
5 | UNTAGGED | DOWN
ML1200(tag-vlan)##
start vlan=all
All pending VLAN's started.
ML1200(tag-vlan)##set-port port=3-5 filter status=enable
Ingress Filter Enabled
ML1200(tag-vlan)##show vlan type=tag
VLAN ID: 1
Name : Default VLAN
Status : Active
(continued on next page)
Note that the VLANs are not started as yet.
Adding the VLAN does not start it by
default.
