CHAPTER 10: VLAN VLAN
MULTILINK ML1200 MANAGED FIELD SWITCH – INSTRUCTION MANUAL 10–17
Converting Port VLAN to Tag VLAN (continued)
-----------------------------------------------
PORT | MODE | STATUS
-----------------------------------------------
1 | UNTAGGED | UP
2 | UNTAGGED | DOWN
6 | UNTAGGED | DOWN
7 | UNTAGGED | UP
VLAN ID: 10
Name : engineering
Status : Active
-----------------------------------------------
PORT | MODE | STATUS
-----------------------------------------------
3 | UNTAGGED | DOWN
4 | UNTAGGED | DOWN
5 | UNTAGGED | DOWN
VLAN ID: 20
Name : sales
Status : Active
-----------------------------------------------
PORT | MODE | STATUS
-----------------------------------------------
3 | UNTAGGED | DOWN
4 | UNTAGGED | DOWN
5 | UNTAGGED | DOWN
VLAN ID: 30
Name : marketing
Status : Active
-----------------------------------------------
PORT | MODE | STATUS
-----------------------------------------------
3 | UNTAGGED | DOWN
4 | UNTAGGED | DOWN
5 | UNTAGGED | DOWN
ML1200(tag-vlan)##
set-port port=3-5 tagging id=10 status=tagged
Port tagging enabled
ML1200(tag-vlan)##set-port port=3-5 tagging id=20 status=tagged
Port tagging enabled
ML1200(tag-vlan)##set-port port=3-5 tagging id=30 status=tagged
Port tagging enabled
ML1200(tag-vlan)##show vlan type=tag
VLAN ID: 1
Name : Default VLAN
Status : Active
(continued on next page)
Enable filtering on the ports required. The
software will prompt to ensure that
connectivity is not disrupted.
VLANs are now active. However, as the
packet traverses VLANs, the packet should
be tagged. This is enabled next.
