CHAPTER 12: SPANNING TREE PROTOCOL (STP) SPANNING TREE PROTOCOL (STP)
MULTILINK ML1200 MANAGED FIELD SWITCH – INSTRUCTION MANUAL 12–9
Configuring STP parameters (continued)
ML1200(stp)##show stp ports
STP Port Configuration
-------------------------------------------------------------------------------
Port# Type Priority Path Cost State Des. Bridge Des. Port
-------------------------------------------------------------------------------
01 TP(10/100) 128 100 Forwarding 80:00:00:20:06:2b:e1:54 80:01
02 TP(10/100) 128 19 Forwarding 80:00:00:20:06:2b:e1:54 80:02
03 100MB Fiber 128 100 Disabled 80:00:00:20:06:2b:e1:54 80:03
04 100MB Fiber 128 100 Disabled 80:00:00:20:06:2b:e1:54 80:04
05 100MB Fiber 128 100 Disabled 80:00:00:20:06:2b:e1:54 80:05
06 100MB Fiber 128 100 Disabled 80:00:00:20:06:2b:e1:54 80:06
07 TP(10/100) 128 100 Disabled 80:00:00:20:06:2b:e1:54 80:07
ML1200(stp)##
priority value=15535
Successfully set the bridge priority
ML1200(stp)##
show stp config
STP CONFIGURATION
-----------------
Spanning Tree Enabled(Global) : YES
Spanning Tree Enabled(Ports) : YES, 1,2,3,4,5,6,7
Protocol : Normal STP
Bridge ID : 3c:af:00:20:06:2b:e1:54
Bridge Priority : 15535
Bridge Forward Delay : 15
Bridge Hello Time : 2
Bridge Max Age : 20
Root Port : 0
Root Path Cost : 0
Designated Root : 3c:af:00:20:06:2b:e1:54
Designated Root Priority : 15535
Root Bridge Forward Delay : 15
Root Bridge Hello Time : 2
Root Bridge Max Age : 20
ML1200(stp)##
priority port=2 value=20
Ports that have connected devices
now participate in STP.
STP is now enabled. Note the default
values for the discussed variables.
