GE RX3i

Chapter 12. Diagnostics
GFK-2224Q January 2017 215
Status
Description
23
Bits
Rack-based and RX7i
Embedded
RX3i Embedded
RX3i CPE330
24
1
Port 1A full-duplex
Port full-duplex
Port full-duplex
LAN 1 stays here for compatibility
with other CPEs.
2
Port 1A 100Mbps
Port operating at highest
supported speed
Port operating at highest supported
speed
LAN 1 stays here for compatibility
with other CPEs.
3
Port 1B full-duplex
Reserved
LAN 2 Port 1 (Top Port) full duplex
4
Port 1B 100 Mbps
Reserved
LAN 2 Port 1 (Top Port) operating at
highest supported speed
5
Network Time Locked
Reserved
Reserved
6
Redundant IP address is active
Reserved
Redundant IP address is active
7
Reserved
Reserved
LAN 2 Port 2 (Bottom Port) full duplex
8
Reserved
Reserved
LAN 2 Port 2 (Bottom Port) operating
at highest supported speed.
9
Any Channel Error (error on any
channel)
Any Channel Error (error on
any channel)
Any Channel Error (error on any
channel)
10
Reserved
Reserved
LAN 2 Port 1 Link Indicates that the
port has link.
11
Reserved
Reserved
LAN 2 Port 2 Link Indicates that the
port has link.
12
Reserved
Reserved
LAN 2 OK Indicates that the
application can get out in the
network on at least 1 port.
13
LAN OK
LAN OK
LAN OK
LAN 1 has only 1 port.
14
Resource problem
Resource problem
Resource problem
15
Module Overtemp (RX3i
rack-based only)
Reserved
Reserved
16
LAN Interface OK
LAN Interface OK
LAN Interface OK
17
Channel 1 Status
SRTP: Data Transfer
Modbus TCP Client: Channel
Open
Channel 1 Status
SRTP: Data Transfer
Modbus TCP Client: Channel
Open
Channel 1 Status
SRTP: Data Transfer
Modbus TCP Client: Channel Open
18
Channel 1:
Modbus TCP Client - Reserved
SRTP Client - Channel Error
Channel 1:
Modbus TCP Client -
Reserved
SRTP Client - Channel Error
Channel 1:
Modbus TCP Client - Reserved
SRTP Client - Channel Error
...
...
...
47
Channel 16 Status
SRTP: Data Transfer
Modbus TCP Client: Channel
Open
Channel 16 Status
SRTP: Data Transfer
Modbus TCP Client: Channel
Open
Channel 16 Status
SRTP: Data Transfer
Modbus TCP Client: Channel Open
