o Role: indicates LACP activity rules for use. Active operation means
port will transmit frames automatically, and passive operation
means port will only transmit messages as response to received
LACP messages from the other side of the link. If Active is selected,
port will transmit LACP packets each second when operating (port
enabled). If Passive is selected, port will not transmit LACP packets
until there is no reception of LACP messages from the other side of
the link;
o Timeout: indicates LACP timeout between transmissions of LACP
packets. Fast will allow transmitting LACP messages each second
and Slow will allow transmitting LACP messages each 30 seconds.
o Prio: indicates port priority to be used by LACP protocol. If LACP
partner try to form a larger group than supported by the device,
this value will be used to define which ports will be used. Lower
priority numbers means higher priority, and group will be created
with higher priority ports. Values allowed are integer numbers from
1 to 65,535.
After one of the configurations described before is changed, user may save or
discard the configurations.
o Save: save configuration at the Running Config;
o Reset: undo changes made locally at the Running Config.
