Static MAC Table Configuration:
If ports are configured as Secure mode, make sure that Management link used to
configure and monitor switch is included. If not, switch’s configuration will be
accessible only by serial interface at USB connection (Local interface).
o Delete: click at the button to delete the MAC address at the row;
o VLAN ID: specify the VLAN that is expected for receiving in frames
from this MAC address. Allowed values are the VLAN allowed
values (from 1 to 4,095);
o MAC Address: specify the MAC address number of the entry
allowed. Values must be inserted in hexadecimal format, and each
octet must be separated by the “-“ signal;
o Port Members: specify which ports allow ingression of frames from
this MAC address. Checkbox selected means port allowed to
receive frames from this MAC address, and checkbox empty
means port not allowed.
After one of the configurations described before is changed, there are buttons that
allows the user to save or discard the configurations
o Save: save configuration at the Running Config;
o Reset: undo changes made locally at the Running Config.
