Chapter 10 – Maintenance and Troubleshooting
GE Reason Switches
REASON SWITCHES-TM-EN-3
279
 Short: means that the pair represented at this cell is
shorted;
 Short Pair: can be for pair A, B, C or D. Means that there is
a cross-pair short at the pair;
 Cross Pair: can be for pair A, B, C or D. Means that there is
an abnormal cross-pair coupling with the pair.
o o Length column:
 The length (in meters) of the cable pair (5-meters
accuracy).
