D
IRECTION 5813707-100, REVISION 2 HAWAII™ SERVICE MANUAL
Chapter 5 - Venue Go™Components and Function (Theory) 5-7
PRELIMINARY
Section 5-4
Venue Go™ Back End (C-BEB)
5-4-1 Back End
The Back End consist of single board called C-BEB, and is responsible for the following scanner
functions:
• Operation of scanner computer based on Skylake processor that operates the Venue Go™scanner
application under Windows 10 Embedded operating system.
• Generation from the +12v and +5v Standby DC supplies, of all the required Back End and Display
supply voltages.
• Support of the external and internal interfaces.
• Storage of Operating System and application on internal SSD.
• Network connectivity (Wi-Fi/LAN).
• Connection to peripherals.
5-4-1-1 Back End Interfaces
The External Interfaces from the Back End are:
• 1 x HDMI Connector located on the Back
• 1 x LAN Connector located on the Back
• 3 x USB3 Connectors located on the Back
• 1 x USB3 Connector located on the Side
5-4-1-2 Solid State Hard Drive
Venue Go™ system contains an internal SSD. The SSD, which is controlled by the CPU, is partitioned
into four logical drives, each of which is designated for different operations, as follows: See Section 5-
12-2 on page 5-26.
