8-2-9 C-FEB Heat Sync Assembly Replacement Procedure
8-2-9-1 Tools
Phillips screwdriver of appropriate size
8-2-9-2 Time Required
5 min
8-2-9-3 Preparations
1.) Shut down the Venue Go™ ultrasound unit, as described in Power Shutdown.
2.) Prepare stable flat surface covered with a soft material (such as foam or thick cloth) to prevent
scratches to the display.
3.) Dismount Venue Go™ system from cart as described in Mounting / Dismounting System on Cart
and place it on a previously prepared surface with the display facing down.
8-2-9-4
C-FEB Heat Sync Assembly Removal Procedure
1) Remove back cover.
2) Remove C-PSB.
3) Remove the fan.
FRU Part #
Refer to Table 9-16 on page 9-17.
• Back Cover Removal Procedure
• C-PSB Removal Procedure
• Fan Removal Procedure
