IRECTION 5813707-100, REVISION 2 HAWAII™ SERVICE MANUAL
Chapter 5 - Venue Go™Components and Function (Theory) 5-9
PRELIMINARY
• Probe Low voltage and High Voltage Supply
• Internal and External HV Mux Control Interface
The C-FEB Interface to the C-IFB (Inlet FANs Board) consists of the following Interfaces:
• Inlet FANs DC voltage supply per the selected Speed Mode.
• 5 Tacho output signals from the FANs to monitor their Speed.
• 5v Standby voltage to the C-BEB
