Gecko in.yj-2 User Manual

22
*
1
Certain current limits may apply. Please talk to your customer service representative for more information.
*
2
Total of Pump 1, O3, heater, and Direct out should not exceed 32 A for TUV (CE/AUS/NZA) version.
*
3
The output voltage for the TUV (CE/AUS/NZA) version will reflect the input voltage, typically 230 V.
*
4
Only available on in.yj-3
*
5
The ozonator is connected in parallel with the Pump 1 low speed, therefore they cannot be controlled independently.
in.yj TUV (CE/AUS/NZA) electrical specifications*
1
Input rating (in.yj-3) : 220 - 240 V nominal with neutral (+5/-10%)
50/60 Hz
Monophase system 40 A max.
Input rating (in.yj-2) : 220 - 240 V nominal with neutral (+5/-10 %)
50/60 Hz
Monophase system 32 A max.
Heat.wav rating :
Voltage : 220/240 V, 50/60 Hz
Wattage : 4 kW at 220 - 240 V
Flow rate : Minimum of 18 GPM (68,1 LPM) is required
Device*
2
Voltage*
3
Maximum current
Pump 1 (2-spd) 220/240 V 15 FLA/60 LRA (inrush)
Pump 2 (1-spd)*
4
220/240 V 15 FLA/60 LRA (inrush)
O3*
5
220/240 V 3 FLA/6 A
Direct out 1 220/240 V 5 A (always on)
Light output 12 Vdc 0,5 AMP (6W Light bulb)
TUV Standards
EN/IEC 60335 - 2 - 60: /A12:2010 - EN/IEC 60335 - 1: /A15:2011
EN55014-1
EN55014-2
EN61000-3-2
EN61000-3-3
